Diamond Paste (High MRR and Great Finishing)
Diamond Paste is used for brush polishing of various shapes of products to obtain superior surface quality.
※ You can check the contents by scrolling left / right.
| GRINDING | POLISHING | LAPPING | SUPERFINISHING |
|---|---|---|---|
| tungsten carbide tool ceramic, glass, comet, PCD tool | Carbide, Ceramic, Seat/Seal, Optics, Precious Metals | Carbide, Dye, Glasses, Metal Seal | Semi-conductor Crystal/Substrate, MRAM Head Electron Optics |
Size Type and Mesh Size Comparison Table
| NO. | Micron Size | Range | Mesh Size |
|---|---|---|---|
| 1 | 1/10 | 0~1/5 | 240,000 |
| 2 | 1/4 | 0~1/2 | 100,000 |
| 3 | 1/2 | 0~1 | 60,000 |
| 4 | 1 | 0~2 | 14,000 |
| 5 | 2 | 1~3 | 11,000 |
| 6 | 3 | 2~4 | 8,000 |
| 7 | 4 | 2~6 | 5,000 |
| 8 | 5 | 3~7 | 4,000 |
| 9 | 6 | 4~8 | 3,000 |
| 10 | 9 | 8~12 | 1,800 |
| 11 | 15 | 12~22 | 1,200 |
| 12 | 30 | 22~36 | 600 |
| 13 | 45 | 36~54 | 325 |
| 14 | 60 | 54~80 | 270 |
Diamond Powder Type
※ You can check the contents by scrolling left / right.
| Type | Features | |
|---|---|---|
| Nat |  |
|
| MA |  |
|
| PC |  |
|
| In addition, the IG type (polycrystalline) has the features of the above MA diamond powder and is inexpensive, thereby used widely in the field of smooth surface processing. | ||
* Beside the sizes listed above, a special-grande size is available.
Plate Type & Purpose
| Kind | CODE No. | 9450 | 410 | 415 | 437 | 431 | 432 | 434 | 435 | Mechano Cloth | Peron PSU |
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 530 | 540 | ||||||||||||
| Rayon(Artificial Fiber) | ● | ● | ● | For Pre-polishing |
For Finishing |
Synthetic fiber, STD, with special air bubbles, is used for rough grinding and the PSU is suitable for long time use. | |||||||
| Cotton | ● | ● | ● | ||||||||||
| Compressed Wool | ● | ● | For chemical LAP | ||||||||||
| Synthetic Fiber Supporter |
● | ● | |||||||||||
|
Diamond Particle Diameter |
Range of use of the HYPREZ Diamond Slurry |
1/10μ | ● | ||||||||||
| 1/4 | ● | ● | ● | ||||||||||
| 1/2 | ● | ● | |||||||||||
| 1 | ● | ● | ● | ● | ● | ● | |||||||
| 3 | ● | ● | ● | ● | ● | ||||||||
| 6 | ● | ● | ● | ● | ● | ||||||||
| 9 | ● | ||||||||||||
| 15 | ● |
|
|||||||||||
|
Abrasive Material |
Finishing for Alumina Sulfur |
● | |||||||||||
| Precision-finishing of Alumina |
● | ● | ● | ● | |||||||||
| Cerium oxide | ● | ● | |||||||||||
| Combined Paste / Lubricant | Water-based Aqueous Oil |
Water-based | Water-based Aqueous Oil |
Water-based | |||||||||
| Size | 105/200/230/380/610/910 (Others are special orders) | ||||||||||||
